Recessed spotlight CLASSIC square copper. Wonderlamp

<

- Brand: Wonderlamp.shop
- Includes GU10 lamp holder (direct to 220v).
- IP: 20.
- Tilting angle: 30º
- Swivel angle: 351º.
- Drill: Ã84 mm (hole in the ceiling)
- Material: Aluminium. IP 20
- 2 year warranty.
- Bulb not included

NO TRANSFORMER NEEDED!

Safety distances.

1.- Between the lamp and non lighted surfaces or objects must not be less than 0.5 m.
2.- Between built-in appliances not less than 0.5m
3.- Between the highest part of the recessed and the ceiling not less than 2.5 cm.
4.- Between the vertical walls (inside the ceiling) and the body of the built-in appliance once installed not less than 7,5 cm.
5.- Check that the bulb is correctly seated in the socket.

Ceiling installation. Before beginning any assembly or installation, make sure that the power has been disconnected.

1.- Drill a hole in the ceiling to ensure a minimum hole and that it does not overlap with beams, pipes or electrical cables (see dimensions of socket hole). Connect the Gu10 lamp holder to the mains supply. Insert the recessed downlight into the ceiling and remove the lamp holder through the hole in the recessed downlight.
2.- No earth connection necessary. If it is possible, make sure that it is totally isolated and that it cannot have any type of contact. Make sure that no metal parts come into contact with any other grounded metal equipment.
